Made for ITX and Small Form Factor enthusiasts, this card is densely packed with performance, and is powered by the NVIDIA Blackwell architecture, DLSS4 and Multi-frame Generation so even the smallest PC builds have the power to play top games with smooth framerates.
Feature Highlights:
–Â Powered by the NVIDIA Blackwell architecture and DLSS 4
–Â 8-Pin PCIe power connector
–Â Half-Height Low-Profile Bracket included
– ITX-Ready ultra-compact Graphics Card
– Fits in 99% of PC builds
–Â All-new FireStorm Utility
| GPU | Â NVIDIA GeForce RTX 5060 GPU |
| CUDA cores | 3840 |
| Video Memory | 8GB GDDR7 |
| Memory Bus | 128 bit |
| Engine Clock | 2497 MHz |
| Memory Clock | 28 gbps |
| AI TOPS | 614 |
| PCI Express | PCI Express 5.0 x8 |
| Display Outputs | 2 x DisplayPort 2.1b with UHBR20 (up to 4K 480Hz or 8K 165Hz with DSC) 1 x HDMI® Connector (Supports 4K 480Hz HDR or 8K 120Hz HDR with DSC, and Gaming VRR as specified in the HDMI 2.1b Specification) |
| HDCP Support | 2.3 |
| Multi Display Capability | Triple Display |
| Recommended Power Supply | 550W |
| Power Consumption | 145W |
| Power Input | 1 x 8-pin power input |
| DirectX | Microsoft DirectX® 12 Ultimate |
| OpenGL | 4.6 |
| Cooling | Air Cooled |
| Slot Size | 2 |
| SLI | NO |
| Supported OS Card Length | Windows 11 / Windows 10 64-bit (v1809 November 2018 or later) |
| Accessories | User Manual Low-Profile Bracket |
| brand | |
|---|---|
| gpu-chipset | |
| gpu-memory | |
| gpu-series |
