MSI CoreLiquid A17 MLG Edition 360mm ARGB CPU Liquid Cooler

MSI CoreLiquid A17 MLG Edition 360mm ARGB CPU Liquid Cooler

Features:

• CycloBlade Design: Focuses airflow and reduces noise.
• ARGB GEN2: Customize the perfect lighting effects for you through MSI CENTER.
• EPDM Tubing: Durable and effective in preventing coolant evaporation.
• Pre-installed Fans: Saves gamers installation time and enhances the assembly experience.
• Enhanced Cooling for Stable AI Performance: Precise heat source targeting for stable CPU performance
• Easy installation: Pre-installed UNI Bracket (1700/1851/AM4/AM5)

UNI BRACKET

The pre-installed and easy-to-use UNI Bracket supports both Intel and AMD sockets, significantly reducing assembly time and improving  the quality of DIY builds for gamers.

EZ CONNECT

The pre-installed fans use hidden daisy-chain connectors to keep cables out of sight, creating a clean, streamlined setup while reducing fan cable management to just two simple connections.

EZ CONN-DESIGN

MSI’s exclusive JAF_1 header opens up more possibilities for DIY enthusiasts. The dedicated JAF_1 header, the header can be converted into an additional ARGB, and FAN headers with the EZ Conn-Cable, streamlining the entire building process.

FAN CycloBlade 9

Delivering powerful airflow and high static pressure. This ensures extreme thermal performance during intense gaming while maintaining low noise levels for an immersive experience.

HIGH THERMAL DISSIPATION

The radiator features 20 FPI (fins per inch), maximizing thermal surface area. Its 12 widened water channels boost water flow by 25% for improved heat dissipation.

EVAPORATION PROOF TUBING

EPDM water thermal tubes resist extreme temperatures, corrosion, and aging, while staying flexible and easy to install with minimal coolant loss.

High Efficiency Pump

Equipped with a high-performance pump. Combined with high-quality ceramic bearings, it achieves a perfect balance between performance and quiet operation.

Full-Plane & Screwless Copper Base

The screwless full-plane copper base improves water-tightness and boosts system reliability. Its 0.1mm micro-channels draw in CPU heat efficiently.

High Efficiency Pump

Equipped with a high-performance pump. Combined with high-quality ceramic bearings, it achieves a perfect balance between performance and quiet operation.

• Radiator Size: 360 mm
• Radiator Dimensions (WxDxH) : 394 x 119.6 x 27.2mm / 15.51 x 4.69 x 1.06 inches
• Radiator Material: Aluminum
• Water Cooling Tube Material: EPDM + IIR
• Number of Fans: 3
• Fan Dimensions (WxDxH): 120 x 120 x 25 mm / 4.7 x 4.7 x 0.98 inches
• Fan Air Flow: 64.89 CFM
• Fan Bearing: Rifle Bearing
• Fan Speed: 500~2050 ± 150 RPM
• Fan Life Expectancy: 40,000 hrs@40℃
• Fan Rated Current: 0.14 A±0.028 A
• Fan Power Consumption: 1.68W±0.336W
• PWM Mode: Yes
• Cable Length (PWM Cable): 600 mm; 23.62 inches
• Fan Lighting: ARGB GEN2
• RGB Connector: 3-pin
• Pump Life Expectancy: 50,000 hours in typical use
• Pump Noise Level: 20 dBA ( Max )
• Pump Rated Current: 0.21A±0.042
• Pump Power Consumption: 2.52W±0.504W
• Pump Speed: 3400 RPM ± 10% RPM
• Pump Connector: 4-PIN Header / 5V ARGB 3-PIN Header ( Female )
• Cold Plate Material : Copper
